Thiazoles and their hydrogenated analogues are not only key structural units in a wide variety of natural products but they also constitute important building blocks in medicinal chemistry. Therefore, the synthesis of these compounds using new protocols is always interesting. It is well known that N-propargylamines can undergo a number of cyclization reactions to produce various nitrogen-containing heterocycles. In this review, we highlight the most important developments on the synthesis of thiazole and its derivatives starting from N-propargylamines. This review will be helpful in the development of improved methods for the synthesis of natural and biologically important compounds.
Keywords: 6-endo-dig cyclization; 5-exo-dig cyclization; N-heterocycles; N-propargylamines; thiazoles
Thiazoles are an important class of azole compounds that have attracted considerable attention due to the fact that they exhibit a wide variety of pharmacological activities. For example, abafungin (Figure 1) is an antifungal drug marketed worldwide for the treatment of dermatomycoses. It works by inhibiting the enzyme sterol 24-C-methyltransferase [1-4]. Febuxostat, also known by its brand name adenuric is a xanthine oxidase inhibitor that helps to prevent gout flare-ups [5-7]. Ritonavir (norvir), is an HIV protease inhibitor. It works by blocking the growth of HIV [8,9]. Tiazofurin is a C-nucleoside analogue with antineoplastic activity and acts by inhibition of the guanosine triphosphate (GTP) biosynthesis through a reduction of PI and PIP kinase activity [10-14] (Figure 1). This compound class is also a crucial part of many natural products such as vitamin B1 (thiamine), epothilone, dolastatin, and many more (Figure 2) [15-24]. Moreover, thiazoles are widely applied as pesticides and dyes . As a consequence, many routes for the synthesis of thiazole derivatives are reported in the literature [26-33]. Among them, the Hantzsch thiazole synthesis (condensation of α-haloketones with thioamides) is the most efficient and straight forward procedure [34-43]. However, the general applicability of this method is limited by the narrow substitution patterns , by the harsh reaction conditions [26,30] or both. Therefore, methods that overcome these drawbacks are required.
The hydrogenated thiazoles (thiazoline and thiazolidine derivatives) are also important structural motifs that are widely found in biologically active natural or synthetic products [44-50]. Compounds containing these rings have widespread biological applications as anticancer [51-53], anti-HIV [54,55], anti-inflammatory , antimicrobial [57-59], and specially antibiotic [60-64] agents. Despite their great relevance in drug design, only very few synthetic methods towards these compounds have been reported to date .
N-Propargylamines are one of the most specific class of alkynes having diverse reaction patterns. It is well known that they can undergo a number of cyclization reactions to produce various N-heterocycles and complex natural products. In this context we recently reviewed their role in the syntheses of pyrrole , pyridine , quinoline , pyrazine , 1,4-oxazepane, and 1,4-diazepane  derivatives. The synthesis of thiazoles and their hydrogenated analogues from N-propargylamines offers several advantages, such as high functional group tolerance and high atom and step economy. In continuation of our works [69-74], in this review, we will highlight the most important developments on the synthesis of thiazole and its derivatives from N-propargylamines (Figure 3) which will be helpful in the development of improved methods for the synthesis of natural and biologically important compounds. The review is organized by the type of starting materials.
The first example of a cyclization of N-propargylamines 1 with carbon disulfide to lead to 5-methylenethiazolidine-2-thiones 2 was reported in 1949 by Batty and Weedon. The reaction took place in refluxing ethanol and generally afforded the corresponding products in good yields. It was also observed that products 2 rapidly formed by reaction of 1 with carbon disulfide in the presence of sodium hydroxide as the base in water at 20 °C. Further, the authors showed that treatment of methylene compound 2 with cold concentrated sulfuric acid gave the corresponding isomeric thiazole-2-thiones 3 in high yields (Scheme 1) . Thirty-six years later, Hanefeld and Bercin synthesized a series of 2-(alkylthio)thiazoles by employing the aforementioned method as the key step . In 2001, Shi and Shen found that using a Pd(PPh3)4/toluene system clearly accelerated this cyclocondensation and the desired products were obtained in excellent yields . Other systems such as Pd(OAc)2/THF , D301R (a tertiary amine-functionalized ion-exchange resin)/biphenyl , and diethylamine/NaOH/H2O  were also successfully employed in this transformation. Despite all these successes, the number of reported examples in this interesting field is limited. There is still further need to study the scope and limitations of this approach for the preparation of thiazolidine-2-thione derivatives.
A straightforward way towards 2-benzylthiazolo[3,2-a]benzimidazole derivatives 6 has been proposed by Balova et al. In their approach, a sequential cyclocondensation/5-exo-dig cyclization process between 2-amino-N-propargylanilines 4 and CS2 afforded heterocyclic systems of type 5. Isomerization of the latter compounds upon heating in the presence of KOH in ethanol gave the corresponding 2-benzylthiazolo[3,2-a]benzimidazoles 6 in good yields (Scheme 2a) . In a closely related investigation, Shafiee and co-workers also found that the cyclocondensation of 2-amino-N-propargylbenzamides 7 with CS2 in a KOH/EtOH system gave the corresponding 2-methylenethiazolo[2,3-b]quinazolinones 8 in good to high yields (Scheme 2b) .
The first example of a synthesis of thiazole derivatives from N-propargylamines and isothiocyanates was reported in 1964 by Easton et al. The authors obtained 2-iminothiazolidines 11 in good yields by the treatment of secondary α,α-disubstituted N-propargylamines 9 with isothiocyanates 10 through a catalyst-free thiourea formation/intramolecular thia-Michael cyclization in ether (Scheme 3a). They also showed that the treatment of primary α,α-disubstituted N-propargylamines with isothiocyanates led to the corresponding N-propargylthioureas that converted to the cyclic forms upon standing for several days at room temperature . Thirteen years later, Arya and co-workers applied this method for the synthesis of 3-thia-1-azaspiro[4,5]decane ring systems . In 1993, U. Urleb extended the scope of the reaction from isothiocyanates to heterocyclic isothiocyanates and some reported examples are shown in Scheme 3b .
This strategy was elegantly used by Sasmal and co-workers in the preparation of 2-aminothiazoles 17 from ethyl 4-aminobut-2-ynoate salts 15 and isothiocyanates 16. Several bases and solvents were screened and the combination of Et3N and THF at room temperature was found to be superior. Under the optimized conditions, the reaction tolerates both aryl and alkyl isothiocyanates 16 and gave the corresponding 2-aminothiazoles 17 in good to high yields (Scheme 4a). The authors further expanded the scope of N-propargylamines to diethyl 3-aminoprop-1-ynylphosphonate salts 18 leading to 5-diethyl methylphosphonate-substituted 2-aminothiazoles 19 in good yields (Scheme 4b) .
An interesting approach towards the synthesis of 2-aminothiazole derivatives by treatment of N-propargylamines with isothiocyanates in the presence of p-toluenesulfonic acid (PTSA) as catalyst under microwave irradiation was developed by Castagnolo et al. Following this route, several 4-substituted 5-methylthiazol-2-amines 22 were synthesized from terminal N-propargylamines 20 and isothiocyanates 21 in DMF at 160 °C. Interestingly, when internal N-propargylamines were treated with 21, exclusively imidazolthiones 24 in yields ranging from 15 to 33% instead of the expected 2-aminothiazoles were obtained. The authors also found that with decreasing reaction temperature the yield of 22 decreased in favor of the thiazolines 23. Some reported examples are collected in Table 1 .
Table 1: Microwave-assisted domino reactions of N-propargylamines 20 with isothiocyanates 21 developed by Castagnolo.
|Entry||R1||R2||R3||Solvent||Temp (°C)||Product||Ratio 22:23:24||Yield (%)|
Recently, to develop an efficient protocol for the synthesis of 5-(iodomethylene)-3-methylthiazolidines 27 from N-propargylamines, X. Zhou and co-workers have investigated the three-component halocyclization of N-propargylamines 25, aryl isothiocyanates 26, and iodine in ethyl acetate. Excellent yields of desired products were observed (Scheme 5). The mechanism shown in Scheme 6 was proposed for this transformation and comprises the following key steps: (i) the reaction of N-propargylamine 25 and isothiocyanate 26 forms the thiourea intermediate A, (ii) electrophilic addition of I2 to the alkyne moiety of this intermediate produces the iodonium intermediate B, (iii) isomerization of iodonium B gives intermediate C and (iv) a sequential intramolecular cyclization and HI elimination of C finally affords thiazolidines 27 .
Seeking for a greener approach towards thiazolidines of type 30, the group of Clausen has proposed a base-catalyzed protocol using t-BuOH in water at 20 °C for a quite efficient cyclization between secondary N-propargylamines 28 and fluorescein isothiocyanate 29 (Scheme 7) .
More recently, Beauchemin and co-workers reported the syntheses of a series of multiply substituted thiazolidines 33 via the cyclization reaction of secondary N-propargylamines 32 with blocked N-isothiocyanate precursors 31. The desired N-isocyanates A are produced in situ upon heating or treatment with a base, in acetonitrile under microwave irradiation conditions (Scheme 8). The reaction tolerated a variety of functional groups such as fluoro, cyano, hydroxy, and methoxy, allowing a further derivatization of the products .
The first example of a thiazole synthesis from N-propargyl thioamides has been reported by Short and Ziegler in 1993. N-Propargyl thiocarbamate 34 cyclized to disubstituted thiazole 35 through an addition–cycloelimination strategy by the treatment with sodium benzenesulfinate and I2 in ethyl acetate and water at 80 °C (Scheme 9a) . Later, the P. Wipf research team found that N-propargylamines 36 were converted to the corresponding vinylthiazolines 38 through the treatment with dithioic acids 37 in the presence of EDCI in dichloromethane. This transformation is believed to occur through a tandem coupling–cyclization reaction. The authors showed that the treatment of 38 with DBU at 0 °C provided thiazoles 39 in good yields (Scheme 9b) .
Along this line, Junjappa and co-workers reported an efficient route for the synthesis of 2-substituted 5-methylenethiazolidines 42 through the reaction of β-oxodithioesters 40 with N-propargylamine (41). The mechanism proposed by the authors to explain this reaction is based on the formation of β-oxo-N-propargyl thioamides A as intermediates, followed by their spontaneous ring closure. This reaction was run in refluxing ethanol and provided in all cases the desired thiazolidines 42 in high to excellent yields (Scheme 10) .
In 2009, Yarovenko and co-workers developed the synthesis of 5-(dibromomethyl)thiazole derivatives 44 by treatment of N-propargyl thioamides 43 with bromine in an ionic liquid (1-butyl-3-methylimidazolium hexafluorophosphate). Mechanistically, the reaction involves: i) bromination of triple bond of thioamide 43 which resulted in a bridged bromonium ion intermediate A; ii) regioselective 5-exo-dig cyclization of intermediate A to give dihydrothiazole B; and iii) addition of a second bromine to the alkene moiety in intermediate B to provide the corresponding thiazole 44 (Scheme 11) .
Recently, Alhalib and Moran reported two examples for the preparation of fully substituted dihydrothiazoles 46 through the treatment of N-propargylamides 45 with Lawesson’s reagent in toluene. It is suggested that the N-(propargyl)thioamide intermediate A is initially formed, followed by a facile 5-exo-dig cyclization process to give the final products 46 in moderate yields (Scheme 12) .
An important study on 2,5-disubstituted thiazoles 49 was carried out by Sasmal, Sridhar, and Iqbal. The authors converted silyl-protected N-propargylamines 47 into thiazoles 49 by their treatment with benzotriazolylthiones 48 in a THF/MeOH/Et3N system (Scheme 13). The proposed mechanism for the reaction starts with the generation of the N-(propargyl)thioamide intermediates A through a thioacylation of N-propargylamine 47 with benzotriazolylthione 48. Then N-desilylation of A furnishes intermediate B which undergoes a base-promoted cyclization to give the intermediate C. Finally, the isomerization of C affords the observed products 49 (Scheme 14) .
In 2011, X. Meng and S. Kim reported an example of thiazolidine preparation through a Mo-catalyzed 5-exo-dig cyclization of the N-propargylthiocarbamate 50 in toluene under irradiation at 350 nm. As shown in Scheme 15 the target 2-phenoxy-substituted thiazolidine 51 was obtained in a yield of 54% along with the product originating from a 6-endo-dig cyclization .
Recently, Foroumadi and co-workers studied the possibility of synthesizing thiazole derivatives from N-propargylthioureas through a regioselective 5-exo-dig cyclization–proton transfer–isomerization sequential process. They found that the easily available N-(propargylcarbamothioyl)amides 53 in the presence of 1,4-diazabicyclo[2.2.2]octane (DABCO) as the base in refluxing ethanol, rapidly cyclized and produced the corresponding dihydrothiazol-2-ylamides 54 in good yields (Scheme 16a). The mechanism for this cyclization as proposed by the authors is depicted in Scheme 16b .
Following this work, the Čikotienė group studied the metal-free halogen, chalcogen, or oxocarbenium ion-mediated cyclization of a series of N-propargylthioureas 55 (Table 2). Some important information of the reactions are listed below: (1) iodine-mediated cyclizations of terminal N-propargylthioureas 55 gave exclusively 4,5-dihydrothiazoles 57 through a 5-exo-dig cyclization, whereas internal N-propargylthioureas 55 under the same reaction conditions gave a mixture of 4H-1,3-thiazines 56 and 4,5-dihydrothiazoles 57. The mechanistic course of this reaction sequence is shown in Scheme 17 and involves the initial formation of the charge-transfer complex A between the iodonium ion and the triple bond. The 5-exo-dig cyclization of this intermediate gives rise to 4,5-dihydrothiazoles and the competing 6-endo-dig ring-closing process affords 4H-1,3-thiazines after conversion of the charge-transfer complex into the ring-opened iodovinyl B or bridged iodirenium C ions; (2) bromine-mediated cyclizations of both electron-poor and electron-rich N-propargylthioureas 55 gave exclusively 4,5-dihydrothiazoles 57 in moderate to good yields; (3) phenyl hypochloroselenoite-mediated cyclizations of terminal N-propargylthioureas 55 underwent a regioselective 5-exo-dig cyclization giving the corresponding 4,5-dihydrothiazoles 57 in moderate yields. On the other hand internal N-propargylamines 55 under the same reaction conditions gave a mixture of 57 and 56; (4) arylideneoxonium ion-mediated cyclization of internal N-propargylamines 55 afforded exclusively the corresponding 4H-1,3-thiazines 56 in good yields. However, terminal N-propargylamines failed to participate in this reaction .
Table 2: Electrophile-mediated cyclization of N-propargylthioureas 55.
|1||H||I2 (2 equiv), DCM, 0 °C||I+||–||20|
|2||Ph||I2 (2 equiv), DCM, 0 °C||I+||18||25|
|3||4-OMe-Ph||I2 (2 equiv), DCM, 0 °C||I+||59||traces|
|4||Ph||NBS (1.1 equiv), DCM, rt||Br+||–||67|
|5||4-OMe-Ph||NBS (1.1 equiv), DCM, rt||Br+||–||68|
|6||4-Cl-Ph||NBS (1.1 equiv), DCM, rt||Br+||–||44|
|7||H||PhSeCl (1 equiv), DCM, 0 °C||PhSe+||–||45|
|8||Ph||PhSeCl (1 equiv), DCM, 0 °C||PhSe+||56||traces|
|9||4-OMe-Ph||PhSeCl (1 equiv), DCM, 0 °C||PhSe+||73||–|
|10||4-Cl-Ph||PhSeCl (1 equiv), DCM, 0 °C||PhSe+||51||–|
|11||H||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||–||–|
|12||Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||81||–|
|13||Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||60||–|
|14||Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||57||–|
|15||4-OMe-Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||76||–|
|16||4-OMe-Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||59||–|
|17||4-OMe-Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||58||–|
|18||4-Cl-Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||57||–|
|19||4-Cl-Ph||ArCH(OR1)2 (1.5 equiv), TMSOTf (1 equiv), DCM, −10 °C||65||–|
Recently, Stevens and co-workers reported a robust protocol towards dihydrothiazoles through an Au(III)-catalyzed intramolecular cyclization of the corresponding dithiocarboimidates. Thus, the corresponding 5-alkylidene-dihydrothiazoles 58 were synthesized in good to excellent yields from N-(propargyldithiocarbo)imidates 57 through a 5-exo-dig cyclization followed by a thio-Claisen-type rearrangement with AuCl3 as the catalyst in dichloromethane (Scheme 18). It is worth mentioning that the required N-(propargyldithiocarbo)imidates were easily prepared in high yields through a condensation of commercially available and cheap N-propargylamine, allyl bromide, and carbon disulfide .
Much work has been carried out during the past decade and has demonstrated that N-propargylamines are one of the most useful and versatile precursors in the synthesis of various nitrogen heterocycles and complex natural products. In this regard, recently an impressive increase in the number of publications on the preparation of thiazoles and their hydrogenated analogues through inter- and intramolecular cyclization of N-propargylamine derivatives appeared in the literature. In this review we discussed the most representative and interesting reports on this emerging field. As illustrated, the processes provided the title compounds in good yields with fewer steps and higher atom economy than previously reported examples. We hope that this review will encourage synthetic organic chemists to employ these valuable methodologies to the synthesis of important new thiazole derivatives.
