Synthesis of ([1,2,4]triazolo[4,3-a]pyridin-3-ylmethyl)phosphonates and their benzo derivatives via 5-exo-dig cyclization

  1. Aleksandr S. KrylovORCID Logo,
  2. Artem A. Petrosian,
  3. Julia L. Piterskaya,
  4. Nataly I. Svintsitskaya and
  5. Albina V. DogadinaORCID Logo

Department of Organic Chemistry, Saint-Petersburg State Institute of Technology, Saint Petersburg, 190013, Russia

  1. Corresponding author email

Associate Editor: I. Baxendale
Beilstein J. Org. Chem. 2019, 15, 1563–1568. doi:10.3762/bjoc.15.159
Received 13 May 2019, Accepted 03 Jul 2019, Published 12 Jul 2019

Abstract

A series of novel 3-methylphosphonylated [1,2,4]triazolo[4,3-a]pyridines was accessed through a 5-exo-dig-type cyclization of chloroethynylphosphonates and commercially available N-unsubstituted 2-hydrazinylpyridines. In addition, 3-methylphosphonylated [1,2,4]triazolo[4,3-a]quinolines and 1-methylphosphonylated [1,2,4]triazolo[3,4-a]isoquinolines were synthesized in a similar manner. The presence of a NO2 group in the starting hydrazinylpyridine induces a Dimroth-type rearrangement leading to 2-methylphosphonylated [1,2,4]triazolo[1,5-a]pyridines.

Keywords: cyclization; fused-ring systems; nitrogen heterocycles; phosphorylation; rearrangement

Introduction

Due to the high polarization of the push–pull triple bond, haloacetylenes show high reactivity in nucleophilic substitution reactions. Our systematic studies of the reactions of chloroethynylphosphonates with various nucleophilic reagents have recently revealed a new direction of this reaction when using C,N-, N,S- and N,N-dinucleophiles. It is characterized by a selective 5-endo-dig cyclization to the corresponding five-membered rings. The obtained new compounds are of special interest due to the practical utility of the formed fused heterocycles, such as indoles [1], thiazolo[2,3-b][1,3,4]thiadiazole [2], and benzo[4,5]imidazo[2,1-b]thiazole [3], as well as due to the simultaneous presence of a biologically active phosphorus function in the molecules. Recently, we have shown that the reaction of chloroethynylphosphonates with 2-aminopyridines proceeds through a 5-endo-dig cyclization to form imidazo[1,2-a]pyridines [4]. In continuation of this study, herein we report an effective approach to the synthesis of new phosphonylated triazolopyridine derivatives by reacting chloroethynylphosphonates with 2-hydrazinylpyridines. The triazolopyridine ring is a structural fragment that is present in a number of drugs and [1,2,4]triazolo[4,3-a]pyridines were shown to have herbicidal [5,6], antifungal [7], neuroprotective [8,9] and antibacterial activity [10]. In addition, [1,2,4]triazolopyridine has been used as electron-acceptor unit in the synthesis of organic light emitting diodes (OLED) [11].

2-Hydrazinylpyridines (a) and pyridinylhydrazones (b), as well as their acylated derivatives (c), are versatile scaffolds for the preparation of triazolopyridines (Scheme 1). The known methods for the [1,2,4]triazolopyridine ring formation use various condensation agents such as HCOOH, orthoesters, Lawesson’s reagent, hypervalent iodine reagents, etc.

[1860-5397-15-159-i1]

Scheme 1: Synthetic approaches to [1,2,4]triazolo[4,3-a]pyridines.

The synthetic methods towards diverse [1,2,4]triazolo[3,4-a]pyridines have been reviewed in detail [12,13]. It should be noted that the use of acetylene species to create this heterocycle (including triazole ring) is presented only by few examples. There has been reported one method for the formation of a [1,2,4]triazolo[4,3-a]pyridine ring with participation of an acetylene triple bond; an oxidative cyclization during the reaction of terminal phenylacetylenes with 2-hydrazinylpyridines [14]. However, data on phosphorus-containing triazolopyridines are scarce, although the phosphoryl fragment widens the range of practical applications of such compounds. In this regard, Marchenko and co-workers [15] have reported the direct P(III)-phosphinylation of [1,2,4]triazolopyridines. The introduction of chlorethynylphosphonates in reactions with 2-hydrazinylpyridines allows to obtain methylphosphonylated triazolopyridine derivatives. Unlike our previous studies, in this case the reaction occurs through a 5-exo-dig-type cyclization.

Results and Discussion

The reactions of chloroethynylphosphonates with 2-hydrazinylpyridines were carried out in acetonitrile with an equimolar ratio of the starting reagents and anhydrous K2CO3 at room temperature. The reaction progress was monitored by 31P NMR spectroscopy. A complete conversion of chloroethynylphosphonate was achieved after 4 hours of reaction (Scheme 2). Note the reactions of 2-hydrazinylpyridines 1af with chloroethynylphosphonates 2 afforded the title [1,2,4]triazolo[4,3-a]pyridines 38 in an almost quantitative yield. It should be emphasized that in the case of 2-hydrazinylpyridines the reaction selectivity is higher than in a similar reaction with 2-aminopyridines, where the formation of trace amounts of the corresponding amidines and amides was observed [4]. Moreover, the formazan-type products, the formation of which was observed in reactions of chloroethynylphosphonates with arylhydrazines, were not detected [16].

[1860-5397-15-159-i2]

Scheme 2: Synthesis of 3-methylphosphonylated [1,2,4]triazolo[4,3-a]pyridines. Reaction conditions: 1 (1 mmol), 2 (1 mmol), K2CO3 (1 mmol), CH3CN (5 mL), rt, 4 h.

The structures of [1,2,4]triazolo[4,3-a]pyridines 38 were confirmed by IR, 1Н, 13C and 31P NMR spectroscopy. Chemical shifts of the phosphorus nucleus for compounds 38 were registered in the range of δP 22–23 and 18–19 ppm for dimethyl а and diisopropyl phosphonates b, respectively. In the 1Н NMR spectra of products 38, the methylene unit was recorded as a doublet signal (δH 3.42–4.19 ppm) with a spin–spin coupling constant of 2JНР ≈ 20 Hz. In the 13С NMR spectra, the methylene carbon resonated as a doublet at δ 23.5 ppm (JCP = 143 Hz). In addition, the structures of triazolopyridines 38 were unambiguously confirmed by the crystal structure of 5b.

Remarkably, the presence of a nitro group in the pyridine ring of the starting 2-hydrazinylpyridines 1i and 1j significantly violates the reaction selectivity, leading to a rapid resinification of the reaction mixture. However, the exclusion of potassium carbonate allows the reaction to proceed selectively within 150 hours at a temperature of 60 °C. The reaction time could be reduced to 30 hours at reflux temperature. It should be noted that in this case the reaction led to the formation of 2 isomers one of which (9, 10) is analogous to the [1,2,4]triazolo[4,3-a]pyridines 38 described above. The formation of another isomer 11, 12, is due to the Dimroth-type rearrangement, which is facilitated by the acceptor nitro group in the pyridine ring (Scheme 3) [17,18].

[1860-5397-15-159-i3]

Scheme 3: Synthesis of methylphosphonylated 6(8)-nitro-[1,2,4]triazolo[4,3-a]pyridines and 6(8)-nitro-[1,2,4]triazolo[1,5-a]pyridines. Conditions: a1 (1 mmol), 2 (1 mmol), CH3CN (5 mL), 60 °C. b1 (1 mmol), 2 (1 mmol), CH3CN (5 mL), reflux. cThe product was not isolated. dThe yield was determined by 31P NMR spectroscopy.

The reaction of 2-hydrazinyl-3-nitropyridine (1i) with dimethyl and diisopropyl chloroethynylphosphonates 2a and 2b proceeded selectively to furnish only [1,2,4]triazolo[1,5-a]pyridines 11. The ease of the formation of isomers 11 in this case and 12 in other similar synthesis, is caused not only by the presence of a nitro group in the pyridine ring, but also by the presence of hydrogen chloride, which is eliminated by potassium carbonate in the former experiments (Scheme 2). The acid-promoted Dimroth rearrangement has been previously reported by Potts et al. [19].

In contrast, the reaction of 2-hydrazinyl-5-nitropyridine (1j) with chloroethynylphosphonates at a temperature of 60 °C for 50 hours led to the formation of a mixture of isomers 10 and 12 in a ratio of ≈1:1. Boiling the reaction mixture after the complete conversion of chloroethynylphosphonate promotes a Dimroth-like rearrangement of [1,2,4]triazolo[4,3-a]pyridine 10 into [1,2,4]triazolo[1,5-a]pyridine 12 completely (Scheme 4).

[1860-5397-15-159-i4]

Scheme 4: Acid-promoted Dimroth rearrangement pathway.

Similar transformations have been observed in the reactions of 2-hydrazinylpyridines with ethyl imidates in the presence of 1.5 equiv of acetic acid [20]. When using highly electron-deficient 2-hydrazinopyridines, the [1,2,4]triazolo[4,3-a]pyridines obtained were converted into [1,2,4]triazolo[1,5-a]pyridines.

The structures of triazolopyridines 1012 were confirmed by IR, 1H, 13C, and 31P NMR spectroscopy, high-resolution mass spectrometry, as well as single crystal X-ray diffraction.

Next, under the conditions applied for the preparation of compounds 38, the reaction of chloroethynylphosphonates with 2-hydrazinylquinoline (1g) and 1-hydrazinylisoquinoline (1h) resulted in the formation of [1,2,4]triazolo[4,3-a]quinolines 13 and [1,2,4]triazolo[3,4-a]isoquinolines 14, respectively (Scheme 5).

[1860-5397-15-159-i5]

Scheme 5: Synthesis of phosphonylated [1,2,4]triazolo[4,3-a]quinolines and [1,2,4]triazolo[3,4-a]isoquinolines. Reaction conditions: 1 (1 mmol), 2 (1 mmol), K2CO3 (1 mmol) CH3CN (5 mL), rt.

In the 31P NMR spectra the chemical shifts of the phosphorus nuclei in 13 and 14 are observed in the 18.40–22.75 ppm region. The 1H NMR spectra contain characteristic doublet signals of the methylene group in the phosphoryl unit resonating at 3.75–4.19 ppm with 2JHP = 20 Hz. At lower field, the signals of 6 protons of the (iso)quinoline rings are present at 7.1–8.7 ppm. In the 13C NMR spectra, the methylene and methine carbons of the triazole ring resonate as doublet signals with characteristic constants of spin–spin interaction with the phosphorus nucleus at 23.43–28.99 ppm (1JСР = 143 Hz) and 53.5–72.1 ppm (2JCP = 7 Hz), respectively. In addition, the structure of phosphonate 14b was unambiguously proved by single crystal X-ray diffraction analysis.

Probably, the reaction proceeds through the nucleophilic substitution of chlorine in the chloroethynylphosphonate to form ynamine intermediate A, isomerization of which provides ketenimine B. Further formation of the imine tautomer C enables an intramolecular 5-exo-dig cyclization to furnish the title [1,2,4]triazolo[4,3-a]pyridines (Scheme 6).

[1860-5397-15-159-i6]

Scheme 6: Plausible reaction pathway.

Conclusion

In conclusion, a series of new 3-methylphosphonylated [1,2,4]triazolo[4,3-a]pyridines, [1,2,4]triazolo[3,4-a]isoquinolines and 1-methylphosphonylated [1,2,4]triazolo[4,3-a]quinolines were synthesized through a catalyst-free 5-exo-dig-type cyclization of chloroethynylphosphonates and commercially available N-unsubstituted 2-hydrazinylpyridines and 2(1)-hydrazinyl(iso)quinolines. Due to the presence of the fused [1,2,4]triazole hetaryl pharmacophore fragment and a phosphoryl group in the obtained compounds they are of great interest as promising substances with potential biological activity.

Supporting Information

Supporting Information File 1: Experimental procedures, characterization data, and copies of 1H, 13C, and 31P NMR spectra for obtained compounds.
Format: PDF Size: 4.4 MB Download
Supporting Information File 2: Crystallographic data for compound 5b (CCDC 1876881).
Format: CIF Size: 17.0 KB Download
Supporting Information File 3: Crystallographic data for compound 12a (CCDC 1906114).
Format: CIF Size: 277.6 KB Download
Supporting Information File 4: Crystallographic data for compound 14b (CCDC 1876879).
Format: CIF Size: 367.1 KB Download

Acknowledgements

We gratefully acknowledge financial support from the Russian Foundation for Basic Research (Grant no. 19-03-00365) and the Ministry of Education and Science of the Russian Federation (project no. 4.5554.2017/8.9). This research made use of resources from the Engineering Center of Saint-Petersburg State Institute of Technology, the Center for Chemical Analysis and Materials, and the Center for X-ray Diffraction Methods of Saint-Petersburg State University.
