In order to further expand the NatureBank open access compound library, chemical investigations of the Australian marine sponge, Ianthella basta, were undertaken since UHPLC–MS analysis of the extract from this sponge indicated the presence of a new alkaloid. Large-scale extraction and mass-directed isolation studies on the CH2Cl2/MeOH I. basta extract resulted in the purification of a new bromotyrosine-derived alkaloid, 5-debromopurealidin H (1), along with the known marine natural product, ianthesine E (2). The chemical structure of the new compound was determined following detailed spectroscopic and spectrometric data analysis. These two compounds (1 and 2) along with seven previously reported marine bromotyrosine alkaloids from the NatureBank open access library, which included psammaplysins F (3) and H (4), bastadins 4 (5), 8 (6) and 13 (7), aerothionin (8) and hexadellin A (9), were evaluated for their nematocidal activity against exsheathed third-stage larvae of Haemonchus contortus, a highly pathogenic parasite of ruminants. Of the nine compounds, bastadin 8 (6), hexadellin A (9) and bastadin 4 (5) showed inhibition towards larval motility after 72 h of exposure with IC50 values of 1.6 µM, 10.0 µM and 33.3 µM, respectively.
Keywords: alkaloid; anthelmintic; biodiscovery; bromotyrosine; 5-debromopurealidin H; Ianthella; NatureBank; sponge
Marine sponges have been a significant source of unique chemistry over the past 70 years, with 11,863 sponge-derived secondary metabolites currently reported in the literature . This equates to ≈30% of all marine natural products identified to date, an impressive contribution. Whilst many marine natural product chemists have shifted their attention to marine-derived microorganisms such as bacteria and fungi over the past 10 years , sponges continue to be a source of novel and biologically active metabolites and remain an important taxonomic phylum for the discovery of new and bioactive natural products, warranting inclusion in current and future biodiscovery programs.
Verongid sponges have been a prolific source of bioactive and novel bromotyrosine-derived alkaloids with more than 374 compounds currently reported . Whilst this particular structure class includes a large number of simple bromotyrosine derivatives, more complex natural products containing spirocyclohexadienylisoxazolines, spirooxepinisoxazolines and oximes have been reported [3,4]. This class of marine alkaloids possess unique functional groups, 3D architecture and interesting pharmacology such as cytotoxicity [5,6], antibacterial [7,8], antimalarial , anti-HIV  and antifouling activities .
Due to our continuing interest in the identification of new secondary metabolites from Australian marine sources, in addition to further expanding the NatureBank  open access compound library, we have recently embarked on a biodiscovery program utilising a subset of marine specimens acquired from the Australian Institute of Marine Science (AIMS)  that have recently been added to the NatureBank biota repository. UHPLC–MS studies of several Verongida extracts from this new collection were analysed in order to identify samples containing abundant or potentially new natural products. A sample from the Australian marine sponge Ianthella basta was chosen for large-scale isolation work after analysis of the UHPLC–MS data and the MarinLit database  suggested the presence of a new alkaloid.
Herein, we describe the large-scale extraction, mass-directed isolation and structure elucidation of a new bromotyrosine-derived alkaloid to which we have given the trivial name 5-debromopurealidin H (1). The anthelmintic evaluation of this new compound, along with seven previously reported and related marine bromotyrosines sourced from the NatureBank open access compound library, is also reported.
While the unique NatureBank HTS-compatible natural product screening libraries (>21K extracts and >105K fractions)  have been regenerated for biodiscovery collaborations with industry and academia over the past 5 years, the NatureBank open access compound library currently contains only ≈100 pure natural products. In an effort to expand this compound library, we have recently embarked on a program whereby a subset of the NatureBank marine and terrestrial extracts have been analysed by UHPLC–MS in order to determine those that contain abundant or potentially new natural products. One such example is the investigation into Verongid sponges; NatureBank holds 63 Verongida specimens that have been recently acquired from AIMS and of these, 39 have adequate material (≥10 g dry weight) for typical large-scale extraction and isolation work. Small-scale (300 mg) extraction of the abundant 39 sponge samples followed by UHPLC–MS and data analysis led to the prioritisation of several extracts for follow-up large-scale chemical investigations (see Figure S1 in Supporting Information File 1 for all UHPLC–MS chromatograms). One extract derived from the marine sponge Ianthella basta showed five UV active peaks (P1–5) at 254 nm in the UHPLC–MS chromatogram (Figure 1) with P1–3 and P5 displaying quasi-molecular ion clusters in the positive MS mode. Subsequent dereplication, literature and MarinLit database  mining tentatively identified P1 as a new monobrominated marine natural product with ions of equal relative intensity at m/z 380 and 382 [M + H]+. Complex ion clusters (abundance ratio: 1:4:6:4:1) at m/z 715/717/719/721/723 [M + H]+, 1014/1016/1018/1020/1022 [M + H]+ and 715/717/719/721/723 [M + H]+ associated with peaks two, three and five, respectively, were tentatively assigned as tetrabrominated metabolites. MS data of P4 was ambiguous and dereplication approaches were unable to successfully assign a tentative structure.
Based on these data, large-scale extraction and mass-directed isolation studies were initiated. The freeze-dried and ground specimen of Ianthella basta (10 g) was sequentially extracted with n-hexane, CH2Cl2 and MeOH, and a portion of each extract was analysed by UHPLC–MS for the ions of interest. Subsequently, the CH2Cl2 and MeOH extracts were combined (which both contained targeted ion clusters) and subjected to reversed-phase C18 HPLC (MeOH/H2O/0.1%TFA) which led to the purification of the new metabolite, 5-debromopurealidin H (1) as its TFA salt along with the major previously reported metabolite, ianthesine E (2) (Figure 2). Comparison of the 1D NMR, MS and specific rotation data for compound 2 with literature values  identified this metabolite as ianthesine E, which had been previously identified from a Pseudoceratina sp. specimen collected from the Great Barrier Reef. 5-Debromopurealidin H and ianthesine E corresponded to peaks one and two in the UHPLC–MS trace, respectively, while metabolites associated with peaks 3–5 in the UHPLC–MS were unable to be obtained in sufficient purity or quantity for structure elucidation studies. Furthermore, insufficient quantities of the raw material of the I. basta specimen prevent further chemical investigation studies at this point in time.
5-Debromopurealidin H (1) was isolated as a stable yellow film. The LRESIMS of 1 showed 1:1 ion cluster peaks at m/z 382/384 [M + H]+ and 380/382 [M − H]−, indicating the presence of one bromine atom . Furthermore, a molecular formula of C14H17BrN5O3 was assigned following analysis of the 1D NMR data in conjunction with the HRESIMS ion at m/z 384.0487 [M + H]+. The 1H and COSY NMR spectra (Table 1) of 1 in DMSO-d6 revealed two distinct spin systems, which included a 1,3,4-trisubstituted aromatic ring [17,18], and an N-substituted ethylene system . Remaining unassigned proton signals included a methylene singlet (δH 3.67), a downfield sp2 singlet (δH 6.55) and four exchangeable protons (δH 7.36, 8.07, 11.84, and 10.11). HMBC correlations from the methylene singlet (δH 3.67, δC 27.8) into the trisubstituted phenyl system and two downfield sp2 signals (δC 151.9 and 163.3), in conjunction with the HMBC data for both exchangeable signals at δH 7.36 and 11.84, and methylene moiety (δH 3.35, δC 39.4) to the sp2 signals (δC 151.9 and 163.3) allowed a N-oxime substructure to be assigned (see Figure 3).
Table 1: NMR data for the TFA salt of 5-debromopurealidin H (1) in DMSO-d6.a
|position||δC, type||δH, mult (J in Hz)||COSY||HMBC||ROESY|
|2||132.8, CH||7.27, d (2.1)||6||3, 4, 6, 7||7|
|4-OH||10.11, brs||3, 4b|
|5||116.2, CH||6.83, d (8.3)||6||1, 3, 4b||6|
|6||129.1, CH||6.99, dd (2.1, 8.3)||2, 5||2, 4, 7||5, 7|
|7||27.8, CH2||3.67, s||2, 6, 8, 9||2, 6|
|9-NH||8.07, t (6.0)||10||9b||10|
|10||37.2, CH2||3.35, dt (6.0, 6.9)||9-NH, 11||9, 12||9-NH, 11, 13|
|11||24.5, CH2||2.59, t (6.9)||10, 13||12, 13||10, 13|
|13||109.3, CH||6.55, s||11||12, 14||10, 11|
a1H, 800 MHz; 13C, 200 MHz; bweak correlation.
MarinLit database mining using this fragment readily identified that compound 1 belonged to the purealidin structure class, the majority of which all contain a terminal imidazole system. HMBC data from the one of the methylene protons (δH 2.59) that constituted the -NHCH2CH2- spin system to the imidazole carbons at δC 124.4 and 109.3 linked these fragments, while a strong HMBC correlation from the imidazole proton at δH 6.55 to the downfield carbon at δC 146.8 indicated a 2-amino substituted histamine moiety . Finally, the unassigned exchangeable protons at δH 10.11 and 7.36, were assigned to phenol (4-OH) and amino groups (14-NH2), respectively, following comparison of NMR data with related previously reported purealidins . While no HMBC correlations were identified for these exchangeable proton signals, the presence of a phenol was further supported by a bathochromic shift that was seen in the UV spectrum of 1 upon addition of base . The bromine atom and phenol hydroxy group were positioned at C-3 and C-4 of the aromatic ring, respectively, based on NMR chemical shift data comparison with related marine natural products . The E configuration for the oxime in 1 was assigned by the diagnostic carbon chemical shifts of the benzylic methylene (C-7, δC 27.8) . Thus, the chemical structure 1 was assigned as 5-debromopurealidin H.
Due to our interest in discovering new anthelmintics from marine sources [22-26], we decided to test these compounds for their nematocidal activity against Haemonchus contortus, a highly pathogenic parasitic nematode of ruminants . A structure-based search of the ≈100 NatureBank pure compound library identified seven previously reported bromotyrosines that were available in quantities that would enable in vitro anthelmintic evaluations. These compounds (Figure 4) included psammaplysins F (3) and H (4), bastadins 4 (5), 8 (6) and 13 (7), aerothionin (8) and hexadellin A (9). The extraction and isolation of these known compounds has been previously reported elsewhere [11,28-30]
Compounds 1−9 were assessed for their activities and potencies in a dose-response assay by measuring the inhibition level on larval motility after 72 h of exposure (Figure 5). Compound 6 was the most potent compound at inhibiting exsheathed third-stage larvae (xL3) motility after 72 h, with an IC50 value of 1.6 ± 0.4 µM (65.2 ± 4.7% inhibition at 100 µM). Two other compounds showed relatively high potency: compounds 9 (IC50 = 10.0 ± 1.9 µM; 47.7 ± 9.5% inhibition at 100 µM) and 5 (IC50 = 33.3 ± 4.7 µM; 49.0 ± 10.2% inhibition at 100 µM). Although not as potent, compounds 1 and 3 were active against xL3s and reduced motility at 100 µM (30.4 ± 16.4% and 35.5 ± 7.1% inhibitions, respectively). Compounds 4, 7 and 8 had no effects on xL3 after 72 h of exposure.
None of the bromotyrosines tested in these studies had previously been tested for anthelmintic activity, however, several of them have been shown to display a variety of biological activities. For example, some ianthesines have been shown to display Na,K-ATPase inhibitory activity  and antimicrobial activity ; ianthesine E has rarely been tested for bioactivity, however, some weak binding has been identified for this molecule against human adenosine A1 receptor 19, along with some weak cytotoxicity towards HeLa cells . Limited testing has also been conducted on the purealidin bromotyrosine structure class, however, quorum sensing inhibition and antifouling activities against several strains of bacteria and microalgae appears in the literature [33,34], while HIV-1 replication inhibition and anti-Leishmania and Plasmodium activity has also been recorded [35,36]. The psammaplysin structure class has also had antimalarial , cytotoxicity  and antimicrobial data reported, albeit with low to moderate potencies . More recently psammaplysin F and several semi-synthetic analogues have been shown to cause loss of mitochondrial membrane potential, fragmentation of the mitochondrial tubular network, chromosome misalignment, and cell cycle arrest in mitosis in LNCaP prostate cancer cells . The bastadin structure class is well-documented within the literature for their cytotoxic activity [37,39-41], with both bastadins 4 and 8 exhibiting in vitro cytotoxicity against leukemia cell line L-1210 (ED50 5 µg/mL) . Aerothionin has been previously shown to exhibit antimycobacterial activity against monoresistant variants of Mycobacterium tuberculosis H37Rv, leading to further reported activity in various M. tuberculosis clinical isolates as well as non-tuberculosis mycobacteria ; while antitumour  and antifouling  activities have also been published.
In summary, we report here the UHPLC–MS profiling of 39 Verongida sponge extracts from NatureBank, which led to large-scale extraction and mass-directed isolation studies on an Ianthella basta specimen and resulted in the purification of a new alkaloid that we named, 5-debromopurealidin H (1). Testing of this bromotyrosine-derived natural product along with several related marine metabolites in an in vitro anthelmintic assay showed that five out of nine metabolites, including 5-debromopurealidin H (1), had activity against larvae of the parasitic nematode, H. contortus. Definitive structure assignments for the unidentified metabolites from the I. basta extract would require recollection of this sponge, which is currently not feasible. Additional Verongida extracts used in the UHPLC–MS profiling reported here will be targeted for follow-up large-scale chemical investigations in the future.
Specific rotations were recorded using a JASCO P-1020 polarimeter. IR data were acquired on a Universal Attenuated Total Reflectance (UATR) Two attachment on a PerkinElmer spectrometer. UV data was recorded on a JASCO V-650 UV–vis spectrophotometer. NMR spectra were recorded at 25 °C on a Bruker AVANCE III HD 500 or 800 MHz NMR spectrometer equipped with a cryoprobe. The 1H and 13C chemical shifts were referenced to the solvent peak for DMSO-d6 at δH 2.50 and δC 39.52, respectively. The UHPLC–MS data were recorded on an Ultimate 3000 RS UHPLC coupled to a Thermo Fisher Scientific ISQEC single quadruple ESI mass spectrometer using an analytical Thermo Scientific Accucore C18 (2.6 μm, 80 Å, 150 × 2.1 mm). HRESIMS data was acquired on a Bruker maXis II ETD ESI-qTOF. Phenomenex Strata solid phase extraction (SPE) cartridges (3 cc, polypropylene, single fritted) were used for the small-scale marine sponge extractions. GRACE Davisil (35–70 µm, 60 Å) C18-bonded silica was used for pre-absorption work before reversed-phase (RP) HPLC. The preabsorbed material was subsequently packed into an Alltech stainless steel guard cartridge (10 × 30 mm) then attached to a HPLC column prior to fractionation. A Waters 600 pump fitted with a Waters 996 photodiode array detector fitted with a Gilson 717-plus autosampler were used for RP-HPLC separations. Frozen marine sponges from AIMS were dried using a Dynamic FD12 freeze dryer and ground using a Fritsch Universal Cutting Mill Pulverisette 19, or by hand using a granite mortar and pestle. For large-scale extraction work, the ground sponge material was extracted at room temperature using an Edwards Instrument Company Bio-line orbital shaker set to 200 rpm. Solvents were removed from crude marine extracts with a Buchi R-144 rotary evaporator and from HPLC fractions using a GeneVac XL4 centrifugal evaporator. All solvents used for chromatography, UV, MS and [α]D were Honeywell Burdick & Jackson or Lab-Scan HPLC grade. H2O was filtered using a Sartorius Stedium Arium® Pro VF ultrapure water system.
The 39 Verongida sponge samples were obtained from the NatureBank biota library housed at the Griffith Institute for Drug Discovery, Griffith University, Australia . All samples were collected and taxonomically identified by AIMS . All sponge samples received from AIMS were freeze-dried, ground and stored at room temperature prior to extraction. The specimen of Ianthella basta (NB6021519; phylum Porifera, class Demospongiae, order Verongida, family Ianthellidae) used in the UHPLC–MS and subsequent large-scale extraction and isolation investigations was collected on the 17 September 2012 from the Timor Sea in the north-western area of the Bonaparte Basin within the Oceanic Shoals Marine Park, Australia. A voucher specimen (G337610) has been lodged at the Queensland Museum, South Brisbane, Queensland, Australia.
Each of the Verongida samples (300 mg) was packed into an SPE cartridge and sequentially extracted with CH2Cl2 (7 mL) and MeOH (7 mL) then combined. The CH2Cl2/MeOH extract was prepared for UHPLC–MS analysis using MeOH to generate a stock solution, which had a final concentration of 1 mg/mL (minimum stock solution volume = 0.5 mL).
All extracts (1 mg/mL) were subjected to UHPLC–MS profiling using an Thermo Scientific Accucore column with an injection volume of 10 µL. Isocratic conditions of 10% MeOH/90% H2O (0.1% formic acid) were employed for the first minute, followed by a linear gradient to 100% MeOH (0.1% formic acid) over 8 min followed by a 1.5 min isocratic elution of 100% MeOH (0.1% formic acid) all at a flow rate of 0.3 mL/min. UHPLC–MS data was analysed using Thermo Scientific Dionex Chromeleon 7 software (Version 7.2.10) at a wavelength of 254 nm.
In a manner similar to Yang et al. , the freeze-dried and ground specimen of Ianthella basta (NB6021519; 10 g) was extracted sequentially with n-hexane (250 mL), CH2Cl2 (250 mL) and MeOH (250 mL × 2). The n-hexane extract was discarded (as it contained only highly lipophilic material) and the CH2Cl2 and MeOH extracts were combined to produce a brown extract (2.36 g). This extract was pre-absorbed to C18-bonded silica (1 g) in 200 mg portions, packed into a stainless-steel guard cartridge (10 × 30 mm) and subjected to C18 semipreparative HPLC. Isocratic HPLC conditions of 90% H2O (0.1% TFA)/10% MeOH (0.1% TFA) were initially employed for the first 10 min, then a linear gradient to 100% MeOH (0.1% TFA) was run over 40 min, followed by isocratic conditions of 100% MeOH (0.1% TFA) for a further 10 min, all at a flow rate of 9 mL/min. Sixty 1 min fractions were collected from time 0 to 60 min to afford 5-debromopurealidin H (1, 11.1 mg, tR 32–34 min, 0.111% dry wt), and the known alkaloid ianthesine E (2, 161.2 mg, tR 40–41 min, 1.612% dry wt).
5-Debromopurealidin H (1): Yellow film; UV (MeOH) λmax (log ε) 283 (3.02) nm; UV (MeOH + NaOH) λmax (log ε) 236 (3.53), 300 (2.94) nm; IR (UATR) vmax 3357, 1678, 1429, 1204, 1140 cm−1; 1H and 13C NMR data, Table 1; (+)-LRESIMS m/z 382/384 (1:1) [M + H]+; (−)-LRESIMS m/z 380/382 (1:1) [M − H]−; (+)-HRESIMS m/z 382.0507 [M + H]+ (calcd for C14H1779BrN5O3, 382.0509).
Ianthesine E (2): Yellow film; + 76.3 (c 0.4 in MeOH), lit. + 50.6 (c 0.3 in MeOH) ; (+)-LRESIMS m/z 714/716/718/720/722 (1:4:6:4:1) [M + H]+, (−)-LRESIMS m/z 792/794/796/798/800 (1:4:6:4:1) [M − H]−.
Haemonchus contortus (Haecon-5 strain) larvae (L3s) were produced and stored using an established protocol  – approved by the animal ethics committee of the University of Melbourne (permit no. 1714374). For use in the assay, L3s were exsheathed and sterilized by incubation in 0.15% (v/v) sodium hypochlorite (NaClO) at 38 °C for 20 min  and then washed five times in sterile saline by centrifugation at 500g (5 min) at room temperature (22–24 °C). After the last wash, exsheathed L3s (xL3s) were suspended in lysogeny broth (LB) containing 100 IU/mL of penicillin, 100 µg/mL of streptomycin and 0.25 µg/mL of amphotericin B – designated LB*.
The bromotyrosine compounds (1–9), were individually tested for their anthelmintic effect on larvae (xL3s) of H. contortus using an established bioassay . Each assay was performed in triplicate on three different days. In brief, compounds were serially diluted in 50 μL of LB* (18-points, 2-fold dilution, 100 µM to 0.76 nM) and dispensed into the wells of sterile 96-well flat-bottom microtitre plates containing 300 xL3s; with six wells with no compound (LB* + 0.25% DMSO; negative control). A plate containing monepantel or moxidectin (positive control compounds) was serially diluted and prepared in the same manner. The motility of larvae was measured at 72 h.
|Supporting Information File 1: UHPLC–UV chromatograms, characterisation data and copies of spectra for 5-debromopurealidin H (1).|
|Format: PDF||Size: 963.8 KB||Download|
The authors acknowledge the Australian Research Council (ARC) for support towards NMR and MS equipment (grants LE0668477, LE140100119, and LE0237908). Research at The University of Melbourne was supported by the ARC and Yourgene Health Singapore (LP180101085). S.H. acknowledges the Griffith Institute for Drug Discovery (Griffith University) for scholarship support.
